CALIBRATION METHODS FOR REPRODUCIBLE AND COMPARABLE ELECTROMAGNETIC PARTIAL DISC

Autor: SIEGEL, MARTIN

Sección: TECNOLOGÍA - Otros libros de Tecnología

CALIBRATION METHODS FOR REPRODUCIBLE AND COMPARABLE ELECTROMAGNETIC PARTIAL DISC

CALIBRATION METHODS FOR REPRODUCIBLE AND COMPARABLE ELECTROMAGNETIC PARTIAL DISC

29,99€ IVA INCLUIDO

Editorial:
DONOSTIARRA
Publicación:
20/11/2020
Colección:
SCHRIFTENREIHE DES INSTITUTS FÜR ENERGIEÜBERTRAGUN
Ver ficha completa

NO DISPONIBLE

Sinopsis

The reliability of electrical energy networks depends on the quality and availability of their electrical equipment, e.g., power transformers. Local failures inside their insulation can lead to breakdowns resulting in high outage and penalty costs. To prevent these destructive events, power transformers are tested for partial discharge (PD) activity in a routine test before shipment. Furthermore, PD activity can be …

The reliability of electrical energy networks depends on the quality and availability of their electrical equipment, e.g., power transformers. Local failures inside their insulation can lead to breakdowns resulting in high outage and penalty costs. To prevent these destructive events, power transformers are tested for partial discharge (PD) activity in a routine test before shipment. Furthermore, PD activity can be evaluated as a diagnostic measurement on-site (on-line or off-line) or be constantly monitored during service using the ultra-high frequency (UHF) method. In this thesis, a calibration procedure is proposed for the UHF method used in power transformers, which is lacking so far. The calibration process is required to ensure both reproducibility and comparability of UHF measurements. Only a calibrated UHF measurement procedure can be deemed reliable and eventually be introduced to supplement in (site-)acceptance tests of power transformers. The proposed calibration method considers two factors: The influence of the UHF sensors' sensitivity and that of the UHF instrument characteristics, including accessories like cables, pre-amplifier, etc. The UHF instruments' influence is corrected by using a defined and invariable test signal as a reference for all recording devices comparable to the calibration method used in IEC 60270 for electrical PD measurement. The sensitivity of the UHF sensor is addressed by a characterization of UHF sensors using the antenna factor (AF) measured in a special reproducible setup, i.e., a GTEM cell. In this thesis, a self-built GTEM cell is presented, which is oil-filled to address the environmental conditions inside a transformer where the sensor will be used. With such a cell, influences on the AF of UHF sensors are investigated, and it is shown that sensor sensitivities measured in an air-filled cell can be corrected to the oil environment. A practical evaluation of the proposed calibration procedure is performed in a laborat
Leer más

Más información del libro

CALIBRATION METHODS FOR REPRODUCIBLE AND COMPARABLE ELECTROMAGNETIC PARTIAL DISC

Editorial:
DONOSTIARRA
Fecha Publicación:
Formato:
Normal tapa blanda (libros)
ISBN:
978-3-7526-2818-0
EAN:
9783752628180
Nº páginas:
128
Colección:
SCHRIFTENREIHE DES INSTITUTS FÜR ENERGIEÜBERTRAGUN
Lengua:
INGLES
Alto:
210 mm
Ancho:
148 mm
Sección:
TECNOLOGÍA
Sub-Sección:
Otros libros de Tecnología
Martin Siegel received his Dipl.-lng. degree in electrical engineering from the University of Stuttgart, Germany, in 2010. From 2011 to 2017, he was an academic researcher at the Institute of Power Transmission and High Voltage Technology (IEH), University of Stuttgart, where he operated in the field of power transformer diagnostics and monitoring, especially unconventional partial discharge measurement methods at power transformers. In 2/2017, he left University to work as Managing Director at BSS Hochspannungstechnik GmbH, being responsible for UHF sensor and monitoring device development. In 10/2020, he successfully defended his PhD thesis entitled "Calibration Methods for Reproducible and Comparable Electromagnetic Partial Discharge Measurements in Power Transformers" at University of Stuttgart, Germany. Martin Siegel has authored and coauthored more than 50 research papers and is an active member of Cigré and German Power Engineering Society VDE-ETG.
